What a magic Pau Grand Prix vista on April 5, 1964.

Jim Clark’s one-litre Formula 2 Lotus 32 Cosworth SCA leads Peter Arundell’s F3 Lotus 27 Ford Cosworth MAE during the 80 lap, 220km race held around the streets of the Pyrenees-Atlantiques city in France’s southwest.

The yellow nose car in third is Richard Attwood’s Lola T54 SCA. Clark won from Attwood and Arundell in a stellar field which included Paul Hawkins, Tony Maggs, Frank Gardner, Jean-Pierre Beltoise, Maurice Trintignant and Denny Hulme.

Jim Clark right up Paul Hawkins’ clacker during the 1964 GP. Hawkeye was seventh aboard John Willment’s F3 Alexis Mk4 Ford Cosworth MAE. There were nine or ten Ford Cosworth MAE, and Renault Gordini engined F3 cars in the F2 race, doubtless to keep numbers up in the first year of the new 1-litre F3 and F2 (LAT)
Dickie Attwood during the ’64 F2 race, Midland Racing Partnership Lola T54 Cosworth SCA. Past Saint Martin Church perhaps, help please Frenchies? (LAT)

It amused me, flicking through some Pau GP photographs that numbers two and four also loomed large the year before, in 1963, when the F1 Lotus 25 Climax V8s of Clark and #4 Trevor Taylor (below) finished one-two from Heinz Schiller’s Porsche 718.

(LAT)

The 1930 French Grand Prix was held on a triangular 15.8km road circuit at Pau. It was won by Philippe Etancelin’s Bugatti T35C, this toe-in-the-water for the town led to the Pau GP’s inauguration as an annual event in 1933.

Marcel Lehoux’ Bugatti T51 won that snowy February race from Guy Moll’s similar car.

The 1930 grid including #10 Lehoux Bug T35B, #44 the winning Etancelin Bug T35C, the #28 or 38 Bugatti of De Maleplane or De L’espee, while towards the top is the #42 Daniel T35B. 25 cars started this race (unattributed)

Happily, the race is still held around the 2.769km Circuit de Pau de Ville.

The Pau GP is up-there in a list of global continuous events. Down the decades it’s been held for GP cars until 1963. It then morphed thru F2 (1964-1984), F3000 (1985-1998), F3 (1999-2006), World Touring Car Championship cars – an unfortunate aberration – (2007-2009) then back to F3 (2012-2012), Formula Renault (2013), then F3 again (2014-2019) until this year (2022) when Vladislav Lomko, a Russian (oh dear, how very passé and politically incorrect) won the May race aboard a Dallara 320 Euroformula (F3 variant) machine.

Far-canal I HATE all the global one-make shit, it’s so fuggin boring. I don’t want to sound like a silly old tugger, but it is boring isn’t it, the lack of variety? And don’t give me the economics lesson, I just don’t give a shit…

Tazio Nuvolari on the way to victory at Pau in February 1935, he is closely followed by Rene Dreyfus, both driving Scuderia Ferrari Alfa Romeo Tipo P3s (unattributed)
Alberto Ascari in the fabulous Ferrari 375 during the ‘51 Pau GP, DNF transmission from Q2. His teammate, Gigi Villoresi, won from pole in another 375. Ascari won in 1952-53 aboard Ferrari 500s (unattributed)

The list of drivers who have won around the demanding track includes many of the gods; Tazio Nuvolari, Jackie Stewart and Lewis Hamilton won once, while JM Fangio, Alberto Ascari and Jack Brabham were victorious twice, Jochen Rindt won thrice during his King of F2 reign, with Jim Clark a four-time winner.

This wonderful poster for the 1963 event shows 1962 first lap action. Jo Bonnier’s Porsche 718 leads Ricardo Rodriguez’ Ferrari 156 and Jim Clark’s Lotus 24 Climax, #8 is Lorenzo Bandini’s 156. Maurice Trintignant’s Lotus 18/21 Climax won from Rodriguez, and Jack Lewis’ BRM P48/57

Throughout motor racing history France has held god knows how many car races on road circuits. It would be a great idea to tour France and tick a few off, for me Pau and Clermont Ferrand are top of the list. Doubtless that’s a function of my age, ten years older perhaps the top-two would be Reims and Rouen…

Jean-Pierre Jabouille aboard his self constructed Elf 2J (nee Jabouille 2J) Renault 2-litre F2 car, from Jacques Laffitte, Chevron B35 BMW during the height of the F2 era in 1976. First to fourth were Frenchmen; Rene Arnoux, Martini Mk19 Renault, Laffitte, Jabouille and Jean-Pierre Jarier, Chevron B35 BMW (DPPI)

The 2-litre F2 and F3000 period of incredibly quick, spectacular racing cars stretched from 1972-1998, any of you who saw the race during that period had a special treat.

Every winner of the Pau classic in that period raced in F1 with the exception of Jorg Muller, who was a test driver for Arrows, Sauber and Williams but never quite got a race-steer.

Mike Thackwell’s Ralt RH6/81 Honda during the June 1981 race won by his teammate, Geoff Lees, Thackwell was sixth (MotorSport)

Red Bull Supremo, Christian Horner raced at elite level including F3000. He is shown below at Pau in 1997 aboard his Lola T96/50 Zyrtec-Judd leading Marcus Friesacher.

It was after following Juan Pablo Montoya for a few laps the following year that Horner realised his future was better devoted to racing outside the cockpit! Still, his management capabilities are enhanced by the knowledge of exactly what his drivers are dealing with.

(MotorSport)
Pau modern era F3 race (unattributed)

Etcetera: 1952 Pau GP…

A couple of days after publication, Australian enthusiast/restorer/vintagent Chester McKaige got in touch and provided these wonderful colour images taken during the 1952 race by his father, George McKaige.

George was doing what we Colonials have always done, the Grand European Tour enroute to the UK. There he worked for the de Havilland Aircraft Company for a couple of years, on his weekends and holidays he attended many British and European racing events taking along his trusty camera.

Twenty years ago Chester printed two volumes of George’s photography in Europe and Australia, my copies of ‘Beyond The Lens’ are among my favourites of that golden-age.

Alberto Ascari in typical race attire, and Ferrari 500 in 1952. Note the stub exhausts fitted at this stage (G McKaige)
Toulo de Graffenried, Plate Maserati 4CLT-48, sixth and final car classified, Pau 1952 (G McKaige)

The XIII Grand Prix de Pau – also the first round of the Grands Prix de France F2 Championship – was won convincingly from pole by Alberto Ascari in a Ferrari 500, chassis #0003 it seems, not #0005, the car in which he won so many races in 1952-53 before passing into the hands of Australians Tony Gaze and Lex Davison.

Sharing the front row with him were Gigi Villoresi’s similar works car, and Lance Macklin’s HWM Alta. Second and third placings in the three hour, 280km race were Louis Rosier’s Ferrari 500 and Jean Behra Simca Gordini T11.

Johnny Claes’ Simca Gordini T15, DNF transmission. Pau 1952 (G McKaige)

By that early stage of the season Ascari had also won the GP di Siracusa. In a year of complete dominance he was also victorious in the GP de Marseille, a heat of the GP di Monza, the GP de Comminges, the GP de la Baule plus the championship Grands’ Prix of Belgium, France, Britain, Germany, Holland and Italy; not to forget the drivers World Championship!

Lance Macklin, HWM Alta, running at the end but unclassified, Pau 1952 (G McKaige)

Credits…

MotorSport Images, LAT, Jean Philippe Gionnet, DPPI, F2 Index, George and Chester McKaige

Tailpiece…

(JP Gionnet)

Lewis Hamilton pinging his F3 Dallara F305 Mercedes through the Esses in May 2005.

He had the perfect weekend, two poles, wins and fastest laps early in the season on the way to winning the F3 Euro Series with victories in 15 of the 20 races – and F1 beyond.

Finito…

James Garner is fitted to a Jim Russell Racing Drivers School Formula 3 car on 14 April 1966…

Jim Russell supervises ‘Pete Aron’s’ preparation for some laps at Snetterton. I wonder exactly what make and model it is?!

The business end of the iconic film ‘Grand Prix’ is about to get underway, the race scenes were filmed, famously, during the 1966 Grand Prix season.

Garner is sharpening his driving skills to cope with the in-car rigours of his role as Peter Aron. Of course he rather enjoyed it all didn’t he, becoming a racer and an entrant of some note.

Garner’s ‘American International Racing’ Lola T70 Mk3B Chev finished second in the 1969 Sebring 12 Hour driven by Ed Leslie and Lothar Motschenbacher behind the winning Penske T70 of Mark Donohue and Chuck Parsons.

By the time these shots were taken in the UK Garner had already done quite a lot of driving under the tutelage of Bob Bondurant in the US, but I wonder if the JRRDS laps were his first in single-seaters?

The ‘Tailpiece’ workshop shot below is on-location at the Cooper, Surbiton, Surrey factory. ‘Pete’ is sitting aboard his Japanese Yamura car which looks rather suspiciously like a Lotus 25 Coventry Climax, the cam-covers of the little 1.5 litre FWMV V8 are removed.

What a film! I wrote a short piece about it ages ago, click here if you’ve not read it, its focus is on Francoise Hardy;

https://primotipo.com/2014/10/17/francoise-hardy-on-the-set-of-grand-prix-1966/

Photo Credits…

Jim Gray, Evening Standard, J Wilds

Tailpiece: Pete being fitted to his Yamura F1 car, July 1966…

The on-circuit shots of the Yamura were of Bruce McLarens 1966 F1 contender, the McLaren M2B that year fitted with Ford, Serennissima and BRM engines. The contract was a nice little earner in the team’s first year in Gee Pee racing. Aron’s helmet design was Chris Amon’s sans the Kiwi logo. Checkout this really interesting article about McLaren’s involvement in the film on mclaren.com;

http://www.mclaren.com/formula1/heritage/action-mclaren-at-the-movies-6114785/


The beautifully finished and trimmed cockpit of Clarks’ Lotus 25 at Monaco 1963. Leather bound Mota-Lita steering wheel, a dash full of Smiths instruments including its famed chronometric tach and right hand change for the 5 speed ZF ‘box. Naked aluminium of the monocoque chassis below the shift lever. (Yves Debraine)

The tell-tale on Jim Clarks Lotus 25 after his retirement from the 1965 Monaco Grand Prix is at 9500rpm…

He was comfortably in the lead of the race by 14 seconds when the car engaged 2 gears at once on the entry to the Gasometer hairpin. Graham Hill inherited a lead he maintained to the race’ conclusion.


Clark in classical pose. Lotus 25 Climax. (Eric Della Faille)

The Lotus 25, the first ‘modern monocoque’ appeared at the Dutch Grand Prix in 1962 and was much copied for the 1963 season. For ’63 the car remained much unchanged other than small details and power increases from the Coventry Climax FWMV 1.5 litre quad cam, 2 valve V8.

Lucas fuel injection was adopted and a changed bore/stroke ratio allowed higher rpm and power.

Lotus retained the ZF gearbox but also tried a 6 speed Colotti-Francis ‘box and later in the season a Hewland 5 speed transmission which would soon become ubiquitous.


Surtees gesticulating at the fast approaching Ginther. (Marti)

John Surtees and Richie Ginther in Ferrari T56 and BRM P57 respectively scrapped for much of the race, this shot is on the entry to the Gasometer hairpin. Ginther tries to pass with Surtees gesticulating in protest.

Ginther finished second to teammate Hill, with Surtees, sitting in a pool of oil and with falling oil pressure finished fourth and set fastest lap on the last lap and the lap record. McLaren was third in his Cooper T66 Climax.


John Surtees eyes focused on a Monaco apex, Ferrari T56/156. (Yves Debraine)

Ferrari competed with interim cars for much of the season using the V6 engines which won the World Championships in 1961. The 1964 car appeared at Monza powered by a V8, the development of the car in ’63 setting up Surtees’ tight title victory in 1964.

dark

Surtees again, here chasing winner Graham Hill’s BRM P57. (unattributed)

clark monaco lotus 25

Clark enroute to what seemed a certain victory, before the intervention of gearbox dramas in his lithe, lissom utterly luvverly Lotus 25. (Unattributed)

hill winner

To the victor, the spoils. Graham Hill ‘The King of Monaco’ after the first of his 5 wins in the Principality. (Getty Images)


Lotus 25 Climax cutaway drawing by James Allington…

This short article makes no attempt to put into perspective one of the most successful and influential racing cars of all time, the first ‘modern monocoque’ includes amongst its relatives all monocoque racing cars built since its debut at Zandvoort in May 1962.

‘Monocoque’ construction by riveted ‘D section’ light alloy longerons attached to fabricated steel bulkheads front and rear.

Front suspension by upper top rocker operating inboard mounted coil spring /damper unit, lower wishbone and adjustable sway bar. Rear suspension by upper top link, inverted lower wishbone and coil spring/damper unit and adjustable sway bars. Cast alloy uprights front and rear.

Girling disc brakes, rack and pinion steering.

Wheelbase 91 inches, track front 51.5 inches, rear 51.75 inches, overall length 146 inches, dry weight 990 pounds. Wheel sizes 5X15 front and 6 or 6.5X15 inches at rear.

Coventry Climax FWMV 1.5 litre 90 degree V8. Bore 67.8mm, stroke 51.6mm, 1496cc, Lucas fuel injection, compression ratio 10.5:1, weight 290lb, 194bhp @ 8500rpm.

ZF gearbox mainly used in 1963 but Colotti and Hewland also tried.

Clark and Chapman

Clark and Chapman with a ’63 spec 25, its essential elements as described above. (Unattributed)

Clarks 1963 Championships…

Clark Zandvoort 1963

Jim Clark, Dutch Grand Prix June 1963. Jim zooms his Lotus 25 between the North Sea sand dunes at Zandvoort on his way to victory. (Yves Debraine)

That Jim Clark and the Lotus 25 were the fastest combination in 1962 was not in doubt but Coventry Climax reliability was not as great as BRM’s that year. In 1963 the promise of ’62 was realised with Clark winning five Grands’ Prix and both the Drivers Championship for himself and the first Manufacturers Championship for Lotus.

Clark finished second in a Lotus 29 Ford in his first foray to Indianapolis and further demonstrated his versatility with wins in cars as diverse as the Lotus 23 sports car and Ford Galaxie touring car/saloon that year.

Clark became the standard by which other drivers were judged in 1963, if not earlier.

Auto Year 13

The cover shot of Clark is at the Dutch Grand Prix, Clark won on the 25’s debut there in 1962 and in 1963 and 1964, all in 25’s and in 1965 in the updated Lotus 33 also Climax FWMV V8 powered.

Oulton Park Gold Cup 1963…

clark winning oulton gold cup 1963

Not only did Jim Clark win the Oulton Park Gold Cup during 1963 but he also recorded some stunning in car footage at the Cheshire circuit in his Lotus 25, such footage very rare at the time.

There were four Non-Championship F1 races in the UK alone in 1963, lucky Brits! The footage is amazing on so many levels not the least of which is a drivers eye period view of the circuit; typical track edges, the lack of run off areas and the topography of trees, ditches and the like for the unwary…and this is a circuit devoid of the ‘special obstacles’ of the ultra dangerous road circuits of the day on which Clark raced. The Nurburgring, Spa, Reims, Pescara and Longford here in Australia spring to mind.

Ok, he is not racing but the precision and accuracy for which he was renowned is also on display…

An ace in every sense of the word.

clark atop 25 oulton park 63

Etcetera…

Lotus 25 camera car

Clark tootling thru the Oulton paddock in his ‘camera car’, its a bit hard to pick out the beefy mount against the dark background. And to think in the day of the ‘GoPro’ this was how it was done only a short time ago. Even when the specialists at Channel 7 in Australia popularised in car footage in the ‘Bathurst 1000’ in the late 70’s the heavy rig occupied a good percentage of the rear seat area…progress! (Unattributed)


Photo Credits…

Yves Debraine, Eric Della Faille, Marti, James Allington cutaway drawing, Automobile Year 13, Peter Windsor
